HP
3586C /004 50Hz-32.5MHz Selective Level Meter
352,000円(税込)
- 仕様
-
50Hz-32.5MHz (50/75ohms) 50Hz-108KHz(600ohms) res0.1Hz acc1*10E-7/year(OPT004)
Frequency 9digits
3dB BW:20Hz,400Hz,3100Hz 60dB-BW:180Hz,2200Hz,3700Hz rejection:75dB(+-2850Hz) Flatness+-0.3dB
Level:-125-+20dBm res0.01dB/0.1dB acc0.20dB
Sprious-115dBm ImageRejection-80dBc IFrejection -60dBc
WideBandPower:-45-+20dBm acc1dB 200Hz-32.5MHz
NoiseLevel -120dBm(20,400HzBW)
Input:BNC(f) UNBAL 50Hz-32.5MHz Banana BAL 50-100KHz(600ohms)
Audio-Out:600ohms WECO Speaker USB/LSB
GP-IB Tracking Generator Out
150VA 177H425W467D 23Kg
OPT004:HistabilityREF 2*10E-7/year
定価201万円
