ASTRO DESIGN

VG849C HDMI Programmable Video Signal Generator

385,000円(税込)

仕様

Video Output;
Dot/Clock Frequency/Step:Analog 5 to 300MHz,1kHz Step
Digital DV 25 to 165 MHz,1kHz Step,HDMI 25 to
165MHz,1kHz Step(Transfer rate 225MHz)
Vertical timing:10 to 300kHz/Max8192Dot,Resolution
1Dot(Analog output only),
Horizontal Timing:15.6 to 200Hz/Max8192 line,
Video Memory:HDMI 4k*4k*36bit(RGB 12bit each),
Analog/DV 4k*4k*24bit(RGB 8 bit each),
Analog Video Signal Output;
Output Signal:R/R-Y,G/Y,B/B-Y,HS,VS,CS,
Video Signal Level:0.30 to 1.2V(75ohm),
Setup Level:0.0 to 0.25V(75ohm),
Composite Sync Signal Level:0.0 to 0.6V(75ohm),
SyncSignal Level(HS,VS,CS):HS and VS >2V,CS +-0.3V,
Scan:Interrace,Non Innterrace,
NTSC/PAL/SECOM:Composite,S-Connection,
HDMI Output;
Color Mode:RGB/YCbCr4:4:4,8,10,12bit, YCbCr4:2:2
8,10,12bit,Internal Sound:8ch(sine,sweep)
External Sound Input:Analog 2ch,Digital COAX or
TOSLINE,Sound Sampling Frequency:32 to 192kHz(Max8ch)
Ver:HDMI,Option Sound:Dolby TrueHD,Dolby Digital Plus
,Dolby Digital,DTS-HD Master Audio,DTS-HD High
Resolution Audio,DTS Digital Surround,DSD(max 8ch),
DVI Digital Output:Single Link RGB 8bit each,

付属品

Power Code,GND leade,Compact Flush(128MB),Compact Flush Adapter,CD-ROM*2(Manual,Programmable Editor),
