Sony

SIR1000W 8ch 20KHz Digital Recorder

231,000円(税込)

仕様

Analog Channel;
Channel:16,32,64,128 ExpandModule 32-128 DC-20KHz(16Ch) DC-20KHz(32ch) DC-10KHz(64ch) DC-5KHz(128ch)
Frequency Response:+0.5/-1.0dB,0dB@200Hz,
Sampling Frequency:Frequency Range*2.4,
Over Range:+33%, Dynamic Range:>80dB,
Input;
Connector:BNC*16,Range:+-0.5,1,2,5,10,20Vpk,
DC Offset:+-100%, Impedance:100kohm,
Max Input:+-100Vpk,
Output;
Connector:BNC*16,Level:+-1,2,5,Variable(+-1 to 5V)pk,
Impedance:50ohm,Maching Resister:>10kohm,
AUX Digital Channel;
Sampling Frequency:384kHz*Speed Ratio,
Connector:BNC*1ch,Level:TTL,
Impedance:10kohm(Input),50ohm(Output),
Voice Channel;
Channel:1ch,
Frequency Range:200Hz-(19.2kHz*Speed ratio),
Connector:Juck,AGC:+-10dB,Max Power;400mW@8ohm,
Cartridge:SDX-T3C or SDX-T3N 25GB

340(W)-115(H)260(D)mm,.7.5kg
定価377.9万円
