JDS FITEL

PS3000 Polarization Dependent Loss Multimeters

132,000円(税込)

仕様

Power Meter mode:
1250-1350nm/1455-1665nm Acc+-0.25(-10dBm) Resolution 0.0001dB
Repeat 0.001+2% dB Dynamic Range >60dB DarkZero
PDL mode:
IEC 61300-3-12:Polarization dependence of attenuation of a single-mode fiberoptic component;Matrix calculation method,
Operating WaveLength :1250-1350nm/1455-1665nm
Resolution:0.01,0.001, or 0.0001dB,
Optimization:1550nm
Absolute Accuracy: Power+-0.25dB(-10dBm) PDL(1455-1655nm)+-(0.005dB)+5%of PDL,
PDL(1250-1350nm)+-(0.010dB+5% of PDL)dB,
Lav(Inseration Loss):(+-0.05dB+2% of Lav)dB,
Dynamic Range: PDL 0-5dB
Fiber type:9/125um SM,FC/PC-Connector
Lav(Inseration Loss)(InGaAs3mm):>60dB,
GP-IB RS232C Relay-Drive
Power Source:100-240Vac 50/60Hz 80VA
Dimensions:21.2(W)-8.9(H)35.5(D)cm,Weight:4kg,

付属品

Power Code
