JDS FITEL

PS3250 Polarization Dependent Loss Multimeters

132,000円(税込)

仕様

Fiber type:9/125um SM, Connector Type:Angled
IEC 61300-3-12:Polarization dependence of attenuation of a single-mode fiberoptic component;Matrix calculation method,
Operating WaveLength : 1250 - 1350 nm and 1455 - 1665 nm
Resolution:0.01,0.001, or 0.0001dB,
Optimization:1310nm,1543nm,1550nm
Absolute Accuracy: Power+-0.25dB(-10dBm) PDL(1455-1655nm)+-(0.005dB)+5%of PDL,
PDL(1250-1350nm)+-(0.010dB+5% of PDL)dB,Lav(Inseration Loss):+-0(0.05dB+2% of Lav)dB,
Dynamic Range: PDL 0-5dB
Lav(Inseration Loss)(InGaAs3mm):>60dB,
Power Source:100-240Vac@50/60Hz,
Dimensions:21.2(W)-8.9(H)35.5(D)cm,Weight:4kg,

付属品

Power Code
