Solartron

1280C Electrochemical Measurement System

1,320,000円(税込)

カテゴリ
部品測定(Component,LCR Meter,MicroScope)
在庫数
1stock
管理コード
lcr209
仕様
Measurement Configuration
Cell connectors :2-,3-or 4-terminal, all floating
Working electrode current
measurement resistor (Rs) range:0.1Ω to 1MΩ
Full scale current ranges:2 A to 200 nA, max. resolution 1 pA
Limit of error:0.1% ± 0.05% of range
Counter electrode output voltage,wrt LO:±20 V
Current, subject to thermal protection limits:2 A
Slew rate, potentiostatic control:10 V/µs
Reference Electrodes
Input impedance:10 GΩ
Input capacitance:50 pF
Max. resolution 1 µV
Limit of error:0.1%±100 µV
DC Polarization
Range ±14.5 V
Limits of error:V3.2 V: 0.2%±200 uV
V3.2 V: 0.2%± mV
Max resolution:100 µV
Current range: ±2 A
Limit of error: 0.2% ±0.1% of range
Max resolution: 100 pA
DC Sweep: (continuous and stepped ramp)
Type analog ramp ramp rate (voltage): 10µV/s to 100 V/s
Segment duration: 10 ms to 105 s
Stepped ramp step height: 5 µV/5 pA to 29 v/4A
Step duration: 10 ms to 105 s
AC Polarization
Waveform Sine
Frequency range: 1 mHz to 20 kHz
resolution: 1 part in 4000
Amplitude ranges 0 to 10 V peak: 10 mV resolution, 0 to 100 mV peak: 100 µV resolution
Distortion 1%
Integration time 0.1 to 105s
Power supply 90 to 110V, 108 to 132V, 198 to 242V, 216 to 264, 48Hz to 65Hz
Power consumption 240VA
Dimensions (w x h x d) 437mm x 198mm x 457mm (17.2in x 7.8in x 18in)
Weight 18.5kg (41lb)
Operating temp. range 0 to 50ºC (32 to 122ºF)

No software(AC/DC Measurement analysis software)
additional fees 1,400,000
付属品
GPIB cable,BNC(m) cable28cm *3 ,BNC(m) banana 1m *4,
12861 ECI Test Module ,Banana-Aligeter *4
User manual,
