YOKOGAWA
DL7200 DC-500MHz 4ch 2GS/s 4MW Digital Oscilloscope
242,000円(税込)
- 仕様
-
DC-500MHz 4ch 2mV-10V/div 1M/50ohms 2GS/s Max4MW/ch 8bit DCoffset BW:20M,100MHz
Sweep:1ns-50s/div acc50ppmTrig:Auto logic width pattern X-Y Zoom Search Cursol
Measure:27item Stat:Max,Min,Std,Ave,Count Math:+,-,Multi,Bin,Integ,Diff,PowerSpectrumGo/No-go
Printer 8.4inch ColorLCD TFT GP-IB MemoryCardATA
Option:
B5/Printer
N3/Logic16ch for 701430
C10/LAN Ether,PC card
7014 30-M/B5/N3/C10
- 付属品
- No Probe
