Yokogawa

AP9945 10Gbps Bit Error Rate Testers

660,000円(税込)

仕様

PPG Function
• Optional variable output supports multiple bit rates:
9.95 Gbit/s to 11.32 Gbit/s, variable in steps of 1 kHz
• Output amplitude:
0.5 Vp-p to 2.0 Vp-p, variable in steps of 10 mV
• Offset:
2.0 V to +3 V, variable in steps of 10 mV
• Crosspoint:
30% to 70%, variable in steps of 1%
• Data and data

ED Function
• CDR function included as standard feature
The CDR signal extracts the clock from the data signal and performs
synchronization when a data signal is the only input. In optical
communications, the CDR function is a useful tool because the data
signal is often transmitted alone.
• In addition to the CDR input port, there are ports for inputting
separate data and clock signals. When this ports are used, the
phases of the data and clock must be matched externally.
• Input ranges:
0.1 Vp-p to 0.7 Vp-p (with CDR), 0.1 Vp-p to 0.6 Vp-p (without CDR)

734001-SG1-F10-F20-T
SG1: Built-in SG
F10 : No generator 1/SG1 required
F20 : No generator 2/F1
required
T : UL/CSA AC125V straight,3 to 2pin Converter

Catalog(English)

付属品

Software,Power Code
