Tektronix
AFG2020 /02 100MHz 2ch Arbitrary Function Generator
198,000円(税込)
- 仕様
-
CH2 ERROR Amplitude Max 2Vp-p (normal 10Vp-p)
Sinwave 100MHz Squarewave 50MHz Triangle,Ramp,Pulse 31MHz
Vertical Resolution: 12-Bit (1/4096) X 256K memory
Resolution Clock: 250 MHz, 1 ppm Accuracy, 0.5 Hz (10 digits)
16 arb waveforms w/ 1K record lengths
Standard Waveforms: Sinewave; Square; Triangle; Ramp; Pulse
Internal AM, FM, PSK, and FSK modulation
External AM modulation
Standard linear/log sweep
Trigger delay (700 ns to 100 s)
Direct DSO waveform transfers without controller
AC 90-250V 300W 9Kg 162H 364W 491D
OPT02 2nd channel with fully independent execution
- 付属品
- Power cord
