Tektronix

492PGM 21GHz Spectrum Analyzer

385,000円(税込)

仕様

10KHz-21GHz Acc +-30KHz at 1GHz
Freq counter acc +-1KHz at 1GHz
Delta Counter acc +-14Hz at 1MHz DF
Frequency Acc 5*10E-5 /year residual FM +-12Hz(1GHz)
Frequency Stability <+-50Hz (1min)
SSB noise -105dBc 30KHz offset at 1GHz
SPAN 0Hz 200Hz-1GHz acc 5%
Resolution Bandwidth 1KHz-3MHz 7.5:1
Video Band width 3Hz-30KHz
Reference Level -117-+30dBm MaxInput CW 1W +30dBm
Pulse Input 75W 1us Duty 0.1%
CRT Log 1-15dB/div Lin 36.9nV-2.8V/div
Input ATT 0-60dB step 10dB
Dynamic Range 80dB(10dBstep)
RF input 50ohm VSWR <1.3 (6GHz)
Calibration 100MHz -20dBm +-0.3dB
1st LO output 2-6GHz +6-20dBm 2nd -6--17dBm
AC 90-250V 48-440Hz 210W 21.3Kg
GP-IB 9 waveform memory

付属品

Power cord, Front panel BNC cable fuse
