HP

4194A /350 10Hz-100MHz Impedance Gain-Phase Analyzer

880,000円(税込)

仕様

Impedance 100Hz-40MHz
0.1mohms-1.6Mohms Acc0.17%
Gain/Phase 10Hz-100MHz -107-+15dBm Measure |Z|,|Y|,Phi,R,X,G,B,L,C,D,Q

OSC 100Hz-40MHz res1mHz
10mV-1Vrms 3digits
DCbias 0+-40V 10mV
4terminal |Z|R,X:10m-100Mohms res100uohms
|Y|G,B:10nS-100S res1nS
Phi+-180deg res0.01deg
L:1nH-100KH res100pH C:10fF-0.1F res0.1fF D:0.001-10 res0.0001

Q:0.1-1000 res 0.1 acc0.17%
Gai/Phase 10Hz-100MHz res1mHz T/R,T,R unit:V,dBm,dBV Phase:deg,rad Delay:s Output -65dBm-+15dBm res0.1dB T/R 0-+-120dB res0.001dB

T,R -107-+15dBm res0.001dB Phase+-180deg res 0.01deg Delay:0.1ns-1s res 0.1ns Sweep:Trig Int/Ext Log/Lin points401 Marker

MultiParameterEquivalentAnalysis Programming20K

HP-IB 400VA 37Kg 375H425W620D　

OPT 350: 50ohm system

付属品

付属品:接続ケーブル,電源コード
Accessory:Connection Cable,Power cord
