HIOKI

7075 4ch 10MHz Waveform Generator

385,000円(税込)

仕様

4ch Function Generator
Max +-10V(RL=inf),Amplitude estanblishment Range;10V range 10 - 0V/OPEN(res1mV),
1V range 1 - 0V/OPEN(res1mV),0.1V range 0.1 - 0/OPEN
(res0.01mV)
DC Offset;10V range -10 to +10V/OPEN
(res1mV),1V range -1 to +1V/OPEN(res0.1mV),0.1V range
-0.1 to +0.1V/OPEN(res0.01mV),Offset Accuracy <0.5%+25mV ,
Output Impedance 50ohm
FUNCTION;
SINE (0-10MHz res 10mHz),SQURE (0-10MHz res 10mHz),TRIANGLE (0-200kHz res 10mHz),RUMP UP (0-200kHz res 10mHz),RUMP DOWN,PULSE (0-200kHz res 10mHz)
NOISE,DC Frequency Accurecy +-(50ppm+50uHz),
DC Output Accuracy +-(2.0%+25mV)
Waveform Memory 128000 word/ch,LPF 50Hz-1MHz ,Sweep
