HP
3324A 21MHz Synthesized Function Sweep Generator
165,000円(税込)
- 仕様
-
1mHz-21MHz res1mHz
SIN 1mHz-21MHz ,Square 1mHz-11MHz ,Triangle/Ramp 1mHz-11KHz
Clock(TTL) 1mHz-60MHz
Resolution 1mHz ( <1MHz) 100mHz ( <21MHz)
Acc +-5*10E-6 Stability 5*E-7/month 5*E-8/week (OPT001)
Output Level 1mV-10Vp-p 50ohms 4digits acc 0.2dB(<100KHz) 0.4dB(<21MHz) 4mV-40Vp-p(OPT02)
PhaseNoise -50dBc (20MHz 30KHzoffset)
Sprious 55dB Harmonic(SIN) -60dBc(0.1Hz-199KHz)
Square Trr<20ns Overshoot 5% Triangle Linerrity 0.05%
DC Offset +-5V (50ohm) 4digits Phase offset +-720deg
Frequency Sweep
Single/Cont Multi-Interval Max100 interval Sequence Max50 Interval
Multi-Marker 1 marker/Interval 9 marker Frequency at 1 Interval
Liner 10ms-10E8sec Log 100ms-10E8sec
AUX-output 21-60MHz 50ohm X,Z,Marker
HP-IB AC100-240V 100VA 132H425W498D 11Kg
